APPLICATIONS & SPECIFICATIONS

This graphic helps describe the mechanical design and physical action employed to accomplish the Sonic destruction of the inert material. The material is introduced in the center and passes through the sonic field therefore causing destruction.

The Sonic Pulverizer has many applications where it proves to be effective. In the case of organics the pulverizer opens up the material making it much easer to digest.

Glass 2 inch -

Vegetables & Grains

Contaminated compost

Rocks 2 inch -

Wood chips 2 inch -

Crystal Granite 2 -

Screen Shot 2020-01-08 at 5.21.54 PM.png

The Sonic Pulverizer will process compost turning all the rocks and glass to a fine sand. It will also reduce hard woods as they pass through the Pulverizer. This is the perfect solution to turning compost with glass and rocks into a fine compost. The Sonic Pulverizer is also perfect for producing sand from glass and quartz.

Specifications

• Dimensions L 16 ft. 10 in. W 4 ft. 9 in. H 13 ft. 11 in.

• Pulverizer weight 17,600 lbs.

• Process capacity 10 - 15 tons per hour

• Requires a magnet, eddy current and metal detector on contaminated compost material

• Requires material screened to 2 inch -

• Requires air pressure 145 psi, suction power 650I/min (172 gallons per minute) inflation performance 520I/min (137 gallons per minute) 5.4 hp 4 kw

• Energy used 80 Kw per hour, power requirements 200 amps 480 volts

• Noise level 90 dBs.

• 3000 up to 15,000 hours life before node overhaul
